JINLIDA LIGHT INDUSTRIAL

Chinese Manufacturer of Gabion Machine

What We Offer

OUR PRODUCTS

Leading enterprise in pipe casting industry

Gabion Mesh Machine

Mesh Straightening Machine

Gabion Mesh Cutting Machine

Edge Winding Machine

Gabion Packing Machine

Wire Pay-off System

Wire Straightening and Cutting Machine

Gabion production line

Gabion Packing Machine

Gabion packing machine is dedicated for gabion mesh's packing, press the gabion to smaller CBM. You can choose single cylinder or double cylinder packing machine. Single cylinder packing machine is suitable for 2m*1m*1m gabion box. Double cylinder packing machine is suitable for 3m*1m*1m gabion box. When the machine work, oil pump unit provide the pressure oil via safety valve limit the pressure and enter manual reversing valve.

INQUIRY

Wire Pay-off System

Wire pay off system is special equipment for gabion machine; the wire will be first send to wire tension?machine and then go through machine. Wire pay off will help wire go through machine more quickly and smoothly. Improve gabion machine work efficiency and output.

INQUIRY

LNWL2 Gabion Mesh Machine

Gabion machine is also known as hexagonal wire netting machine, which?is the professional machine to produce?hexagonal wire?mesh. Jinlida series machines are designed to make gabion mesh of various widths and mesh sizes, we can produce the machine as your size. PLC control system touch screen is available for the hexagonal wire mesh machine. It is supposed to be in continuous and smooth operation,?saving much labor force. Adopted with central automatic lubrication system, so as to make feeding guideway to have the good performance for little resistance, little friction, good lubrication and long life etc. Jinlida gabion machine use eccentric reed pipes, do little harm to wire coating layer, reduce machine overload. One set of gabion machine includes four main parts: mesh weaving machine, spring coiling machine, mesh winding machine and wire tension device.

INQUIRY

LNWL3 Gabion Mesh Machine

INQUIRY

LNWL4 Gabion Mesh Machine

INQUIRY

Edge Winding Machine

The edge banding machine is is dedicated for hexagonal wire netting, it is a part of gabion production line. Edge winding machine is used for winding up the gabion mesh sheets edge, helping make the gabion box and gabion mattress.It is used for selvedge, to make the twisting wire heads after mesh sheared to be rolled on a thick side wire. The new edge will be flat, smooth and beautiful. Machine is controlled by PLC control system. The design aims at automatic operation, easy regulation, simple maintenance and high productivity. The edge curl system of machine can be adjusted according to the mesh. For better operation, smooth netting sheet and same mesh size are ensured.

INQUIRY

Mesh Straightening Machine

The wire mesh straightening machine can?manually adjust pressure to realize?the flat netting sheet. It?has separate transmission and handle control button, it can realize the upper roller's alone adjustment, inching and continuously sending mesh into the material roller, it is easy to cooperate and grasp.

INQUIRY

Gabion Mesh Cutting Machine

The cutting machine is combined with mesh straightening machine and mesh conveying machine. It is controlled by PLC control system, you can take three working condition you want. The mesh shearing machine is controlled with PLC control system. You can set the time of electromagnet, number of mesh, speed of mesh conveying roller and length of mesh conveying.

INQUIRY

About Us

Jinlida Light Industrial

JINLIDA many thanks customers used our gabion machines. Since no machine like it existed before, It was developed by utilizing both homegrown technology and that from abroad. We have developed the machine from model LNWL-1,LNWL-2 to LNWL-3 during these years, We also have much international professional technical service experience both for machinery and gabion system construction.

Company Profile

Factory Tour

Cases

QUALITY ASSURANCE

Products for a wide application in petroleum,mine,construction,erosion & sediment control and other industries.

PRODUCTIVE POWER

With professional production lines, our output reaches 10 million square meters pre year.

INNOVATIVE R&D

Jinlida gabion mesh machine has received its patents in china in 1999 and 2000.

24-HOUR AFTER SERVICE

The products are exported to overseas markets such as the United States, Eastern Europe and Southeast Asia, providing 24-hour timely service

APPLICATIONS

The products are widely used in oil, construction, raising, chemical industry, warming piping and etc. It is also used in fence, apartment and greening

Petroleum Industry

Products for a wide application in petroleum, mine, construction, erosion & sediment control and other industries.

Construction Industry

Products for a wide application in petroleum, mine, construction, erosion & sediment control and other industries.

Chemical Industry

Products for a wide application in petroleum, mine, construction, erosion & sediment control and other industries.

Warming Piping

Products for a wide application in petroleum, mine, construction, erosion & sediment control and other industries.

NEWS EVENTS

Industry News

Company News

Jinlida's patented technology
